Brand |
Fingers |
Model Number |
2D-QuickScan WL5 |
Supported Interfaces |
USB Receiver |
Type | Wireless BT Wired |
Input Voltage | DC 5 V ± 5% |
Operational Modes |
Scan |
Color |
Black |
Frequency |
2402 MHz ~ 2480 MHz |
Effective Range | 30 - 50 meters (Open Space) |
Working Current |
280 mA |
0 mA | |
Sleep Mode | 26 mA |
Housing Materia |
ABS+PC |
Charging Cable Type | USB Type-C (1.20 meters) |
Dimensi |
15.4 (H) x 8.5 (W) x 6.2 (L) cm |
Weight | 201 grams (without receiver) |
Indicators |
Beeper, LED |
Operation Mode | Trigger |
In-built Memory |
4 MB |
Light Source |
617 nm LED Aimer, White LED |
Scan Rate | 200 scans/sec |
Resolution | 1D ≥ 5 mil 2D ≥ 10 mil |
Depth of Field | EAN13 50-200 mm (13mil) QR 25-240 mm (20 mil) PDF417 30 - 130 mm (6.67 mil) |
Print Contrast Ratio | 20% |
Battery Type |
Lithium |
Battery Capacity | 1400 mAh |
Charging Type | USB Type-C cable |
Charging Time | About 5 hours |
Barcode Type |
Wireless |
Operating Temperature |
0°C – 40°C |
Shock Resistance Country of Origin Warranty |
.5 m drops China 1 Year |
Barcode Type Support
1D: EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar,Interleave 2 of 5, ITF-6, ITF-4, ISBN, ISSN, MSI-Plessey, GS1 Databar, GS1 Composite Code, Code 11, Industrial 25, Standard 25, Plessey, Matrix 2 of 5
2D: QR Code, Data Matrix, PDF417, Aztec, Maxicode, Micor QR, Micor PDF417, Hanxin Code
